Accuracy specifications
|
|
AC volts
(40Hz to 500Hz) 1
|
Range
|
Resolution
|
Precision
|
|
6.000 V
60.00 V
600.0 V
|
0.001 V
0.01 V
0.1 V
|
1.0 % + 3
|
|
DC volts
|
6.000 V
60.00 V
600.0 V
|
0.001 V
0.01 V
0.1 V
|
0.5 % + 3
|
|
AC millivolts
|
600.0 mV
|
0.1 mV
|
3.0 % + 3
|
|
Diode test 2
|
2.000 V
|
0.001 V
|
10 %
|
|
Resistance
(Ohms)
|
400.0
4.000
40.00
400.0
4.000
40.00
|
0.1
0.001
0.01
0.1
0.001
0.01
|
0.5 % + 3
0.5 % + 2
0.5 % + 2
0.5 % + 2
0.5 % + 2
1.5% + 3
|
|
Capacitance 3
|
50.00 NF
500.0 NF
5.000
50.00
500.0
1000
|
0.01 NF
0.1 NF
0.001
0.01
0.1
1
|
2 % + 5
2 % + 5
5 % + 5
5 % + 5
5 % + 5
5 % + 5
|
|
Frequency 4
Hz
(10 hz-100 khz)
|
50.00Hz
500.0Hz
5.000 kHz
50.00 kHz
100.0 kHz
|
0.01Hz
0.1Hz
0.001 kHz
0.01 kHz
0.1 kHZ
|
0.1 % + 3
|
|
Duty cycle 4
|
1% to 99%
|
0.1 %
|
1% typical 5
|
|
AC current
(40Hz to 200Hz)
|
4.000A
10.00A
|
0.001A
0.01A
|
1.5 % + 3
|
|
DC current
|
4.000A
10.00A
|
0.001A
0.01A
|
1.5 % + 3
|
|
1. All AC, Hz, and duty cycle ranges are specified from 1% to 100% of range. Inputs below 1% of range are not specified.
2. Typically, open-circuit test voltage is 2.0V and short-circuit current is <0.6mA.
3. Specifications do not include errors due to lead capacitance and floor capacitance (which can be up to 1.5nF in the 50nF range).
4. All AC, Hz, and duty cycle ranges are specified from 1% to 100% of range. Inputs below 1% of range are not specified.
5. Typical means when the frequency is at 50Hz or 60Hz and the duty cycle is between 10% and 90%
|
|
Function
|
Overcharge protection
|
Input impedance (nominal)
|
Common-mode rejection ratio
|
Normal-mode rejection ratio
|
|
AC volts
|
600 V 1
|
> 10 <100 pF 2
|
> 60dB at DC,
50Hz or 60Hz
|
?
|
|
AC millivolts
|
600 mv
|
> 1 m, <100 pF
|
> 80dB at 50Hz or 60Hz
|
?
|
|
DC volts
|
600 V 1
|
> 10 <100 pF
|
> 100dB at DC,
50Hz or 60Hz
|
> 60dB at 50Hz or 60Hz
|
|
1. 6x105 V Hz max
2. For mV (AC), input impedance is approximately 1.
|
|
General specifications
|
|
Maximum voltage between any terminal and earth ground
|
600 V
|
|
Display (LCD)
|
6000 counts, updates 3/sec
|
|
Battery Type
|
2 AAA, NEDA 24A, IEC LR03
|
|
Battery Life
|
200 hours minimum
|
|
Temperature
|
|
Operation
|
0°C to 40°C
|
|
Storage
|
-30°C to 60°C
|
|
Relative humidity
|
|
Operating humidity
|
Non-condensing when <10°C
% at 10°C to 30°C; % at 30°C to 40°C
|
|
Operating humidity, 40 range
|
% at 10°C to 30°C; % at 30°C to 40°C
|
|
Altitude
|
|
Operation
|
2000 m
|
|
Storage
|
12.000 m
|
|
Temperature coefficient
|
0.1 x (specified accuracy)/°C (<18°C or >28°C)
|
|
Fuse protection for current inputs
|
11A, 1000V fast fuse, Fluke specified part only
|
|
Size (HxWxL)
|
142mm x 69mm x 28mm
|
|
Weight
|
200g
|
|
Protection Rating
|
IEC 60529: IP 40
|
|
Security
|
IEC 61010-1: 600V CAT III, Pollution Degree 2
|
|
Electromagnetic environment
|
IEC 61326-1: Portable
|
|
Electromagnetic compatibility
|
Applies to use in Korea only. Class A equipment (industrial broadcasting and communication equipment)1
|
|
1 This product meets the requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take note of it. This equipment is intended for use in business environments and is not to be used in homes.
|
